XS-4016
COSO
Product Description
The COSO X-ray inspection machine uses material density recognition to clearly view the internal structure of products. It can detect contaminants like metal, bones, glass, stones, and ceramics, providing reliable support for quality control and safety inspections. The system identifies foreign objects, such as bones in salmon or impurities in food, as well as defects like rotting fruit, dented bottles and cans, or broken items. This technology is widely used across various industries, including fruits, aquatic products, vegetables, prepared foods, and snack foods, ensuring standards of safety and product quality.
Product Image
These two pictures showcase the imaging capabilities of the COSO X-ray inspection machine. The first picture compares different stages of mango decay, clearly highlighting the decayed areas, which helps identify quality issues in the product. The second picture compares the physical salmon with its X-ray image, where the machine clearly shows the salmon bones, ensuring no foreign objects are present. These advanced imaging technologies provide precise and reliable support for quality control and safety inspections.
Mango
Salmon
Image Program
The new image enhance ment engine makes detailed imaging clearer, which has greater advantages in improving the detection rate of foreign objects and defects and reducing the false alarm rate.
Intelligent Algorithm
The algorithm can collect samples in real time and improve detection capabilities through continuous learning.
While detecting foreign object in the product (metal, stone, ceramic, glass, bone), it can also simultaneously detect defects, such as poor product form, including incompleteness, fracture, breaks, overlap, etc., effectively preventing the outflow of defective products. Product counting & integrity detection in opaque product packaging. Reduce the impact of desiccant & deoxidizer.
Product Details
Convenient Operation
Equipment parameters are basically free of debugging, the software operation is user-friendly and easy to understand.
Product Specification
| Model | XS-4016 | XS-5025 | XS-6030 | XS-8050 | |
| Structure | Tunnel width | 400 mm | 500 mm | 600 mm | 800 mm |
| Tunnel height | 160 mm | 250 mm | 300 mm | 500 mm | |
| Dimension | 2009(H)*1094(L)*902(W) mm | 2009(H)*1500(L)*1180(W) mm | 2140(H)*1500(L)*1280(W) mm | 2301(H)*2021(L)*1635(W) mm | |
| Weight | 380 kg | 500 kg | 600 kg | 800 kg | |
| Frame material | SUS304 | SUS304 | SUS304 | SUS304 | |
| Conveying | Conveyor material | Food grade PU | Food grade PU | Food grade PU | Food grade PU |
| Conveyor width | 400 mm | 500 mm | 600 mm | 800 mm | |
| Height from conveyor to ground | 800±50 mm | 800±50 mm | 800±50 mm | 800±50 mm | |
| Conveyor speed | 10–60 m/min | 10–60 m/min | 10–60 m/min | 10–60 m/min | |
| Max load | 10 kg | 15 kg | 20 kg | 30 kg | |
| X-ray | X-ray tube voltage | 40–80 kV | 40–80 kV | 30–80 kV | 60–120 kV |
| X-ray tube current | 200~5000 μA | 200~5000 μA | 4000~7500 μA | 200~7500 μA | |
| X-ray power | 210 W | 210 W | 350 W | 480 W | |
| Sensitivity | Stainless steel ball（Φ） | 0.3 mm | 0.3 mm | 0.5 mm | 0.5 mm |
| Stainless steel wire | 0.2*2 mm | 0.2*2 mm | 0.3*2 mm | 0.3*2 mm | |
| Glass ball（Φ） | 1.0 mm | 1.0 mm | 1.5 mm | 1.5 mm | |
| Ceramic ball（Φ） | 1.0 mm | 1.0 mm | 1.5 mm | 1.5 mm | |
| Configuration | Protection level | Conveying part： IP66 | |||
| Other sections： IP54 | |||||
| Rejection | NG belt stops; automatic rejecction (optional) | ||||
| Alarm mode | Sound and light alarm | ||||
| Display | 21.5 inch touch screen, resolution 1920*1080 | ||||
| Cooling | Industrial air conditioner | ||||
| Protection | Four layers of industrial-grade lead curtains | ||||
| X-ray leakage | ≤1μSv/h | ||||
| Working temperature | -10–40℃ | ||||
| Working humidity | 30–90% RH，no frost | ||||
Note:
The detection sensitivity is the test result obtained by the material blocks falling freely through the detection pipeline. The actual sensitivity may be different accordingly to the characteristics of the tested products or the working environment, it should be based on the actual detection sensitivity.
Models listed in the table are just standard configurations. Our actual production includes numerous variants not exhaustively listed here. For other requirements, please contact customer service for details.
